CYCLIC VOLTAMMETRY

Description

Cyclic Voltametry:

• Support 3 electrode system: Screen printed electrode / Accommodate other Electrodes (WE, CE and RE) separately
• Floating (isolated from earth) or earth ground
• Potential control voltage range: ± 2.3V
• Applied potential accuracy: ± 1 mV
• CV step potential range: 1 mV to 20 mV
• Current control range : ± 100 mA maximum
• Current sensitivity: 1 pA
• CV scan rate: 1 to 100 mV / sec
• Number of scan : 1 to 5
• Plot storing Capacity: Max 999
• CV current range is automatic during scan
• 3.5 inch T.F.T. display used as a HMI
• Manually adjustable gain
• Data available in Microsoft Excel sheet
•  Input Power : 220 V AC
